Northpoint Engines 115HP Inline-4 4-Stroke — 20" Shaft in Gloss White
Gloss White
Cowling Finish — Gloss White
Northpoint Engines

115HP Inline-4 4-Stroke — 20" Shaft

1.8L SOHC inline-four with closed-loop fuel injection. Tuned for aluminum fishing rigs and pontoons in the 16-20 ft class; the 2.15:1 gear ratio swings larger props for heavy-hull thrust. Closed-loop EFI maintains optimal air-fuel mixture across the operating range for clean starts and steady fuel economy.

Crated, freight-ready
$11,299
USD. Freight and applicable taxes calculated at checkout.
  • 256-Bit SSL
    Encrypted checkout
  • Factory Warranty
    Included on every unit
  • Freight-Insured
    Crate damage covered
  • Authorized Dealer
    Direct from OEM channels
Shaft Length

Match your transom height. Measured top of transom to keel.

Will It Fit My Boat?

Smart Compatibility Checker

Enter your transom measurement and the USCG max-HP plate rating from your hull.

Zero-Question Specification Matrix

Every spec, no calls required

Horsepower
115 HP
Stroke
4-Stroke Inline-4
Displacement
1832 cc
Cylinders
4
Operating RPM Range
5300 – 6300 RPM
Gear Ratio
2.15:1

What's in the Crate

Each engine ships on a reinforced LTL pallet. Crated weight approx. 458 lb.

Included
  • Powerhead with factory-sealed cowling and cylinder cover
  • Mounting hardware kit — BIA standard, 13-1/8" x 5"
  • Integrated power trim/tilt assembly (pre-charged)
  • Owner's manual, warranty registration card, and rigging diagrams
  • Anode set installed (saltwater-grade zinc/aluminum)
Sold Separately
  • Propeller (sold separately — see compatible diameters in specs)
  • Throttle/shift controls, harness, and key switch
  • Rigging gauges (tach, fuel, trim) and digital display
  • Battery, battery cables, and isolator
  • Steering helm, hoses, and hydraulic fluid

Freight & Transit Estimator

LTL liftgate delivery to the lower 48. Carrier calls to schedule a 4-hour window.

Enter a ZIP to see a transit and zone estimate. Exact carrier rates confirmed at checkout.
Crated weight
458 lb
Crate dims
60" × 32" × 42"
Carrier class
LTL Class 85
Signature
Required at delivery

Compatibility & Rigging FAQ

Mechanical and electrical facts for your rigger. Specifications follow ABYC and OEM service standards.
